3 wheels non-detachable portable scooter for elderly used（B1）

Product parameters
Model Tricycle B1-S (without shock absorption)
Size 1100mm*520mm*970mm
Motor power 250W
Controller Dynamic/Dynamic
Cushioning NO/YES
Battery 24V 12A/20A battery
Range 20KM/30KM/45KM
Manned Single
Speed 0-8KM/H
Brake mode automatic
Front-wheel 7 inches
Rear wheel 7 inches
Net weight 37KG (without battery)
Max. load 150KG
Trench crossing capacity ≤4CM
Climbing capacity ≤12°
Rotation radius ≤1.2M
Charging time 6 hours







4 wheels Shock-absorbing non-detachable single-seat battery operated large elderly mobility scooter

Product parameters
Model Big Bike Single (with shock absorption)
Size 1520mm*650mm*1340mm
Motor power 500W
Controller Strawberry
Cushioning YES
Battery 24V 40A/50A/60Abattery
Range 30KM/45KM/55KM
Manned Single
Speed 0-8KM/H
Brake mode automatic
Front-wheel 12-inch pneumatic tire
Rear wheel 12-inch pneumatic tire
Net weight 75KG (without battery)
Max. load 150KG
Trench crossing capacity ≤4CM
Climbing capacity ≤12°
Rotation radius ≤1.2M
Charging time 6 hours
